Description
The Honeywell M6194B1011 is a heavy-duty Floating Modutrol IV Motor engineered for precise damper and valve positioning in commercial and industrial HVAC systems. Delivering 300 lb-in of torque with a 24Vac power supply, this non-spring-return actuator is built to handle demanding modulating control applications where reliable, repeatable positioning is critical.
Key Features
- 300 lb-in torque output for robust damper and valve actuation
- 24Vac operating voltage for compatibility with standard commercial control systems
- 60 to 120 second nominal timing for smooth, controlled stroke movement
- 1 auxiliary switch included for end-of-travel or interlock signaling
- 90 to 160 degree adjustable stroke for flexible application fit
- Non-spring-return design maintains last position on power loss
- Foot-mounted configuration for easy installation and secure mounting
- Dual-ended square shaft for versatile linkage connections
- Integral junction box provides NEMA 3 weather-resistant protection
Application
The M6194B1011 is ideal for use in air handling units, commercial damper systems, and large valve actuator applications requiring high torque and adjustable stroke. The floating control action allows the motor to respond to two-position or floating signals from building automation systems and standalone controllers alike.
Specifications
- Model: M6194B1011
- Series: Modutrol IV
- Control Type: Floating
- Torque: 300 lb-in
- Supply Voltage: 24Vac
- Nominal Timing: 60–120 seconds
- Auxiliary Switches: 1
- Adjustable Stroke: 90–160 degrees
- Return Type: Non-spring return
- Mounting: Foot mounted
- Shaft Type: Dual-ended square shaft
- Enclosure Rating: NEMA 3 (via integral junction box)
