Honeywell 009640 Permanent Split Capacitor Motor Overview
The Honeywell 009640 is a heavy-duty Permanent Split Capacitor (PSC) motor engineered for reliable performance in demanding HVAC and air-handling applications. Delivering 1/4 horsepower at 115 VAC single-phase power, this motor is built to handle the rigors of condenser fan and blower duty where dependable, efficient operation is essential.
Key Features
- 1/4 HP output for efficient air-moving applications
- 115 VAC, single-phase power supply
- 2-speed operation for flexible airflow control
- 1100 RPM operating speed
- 3.4 amp full-load current draw
- 48Z NEMA frame size for broad OEM compatibility
- Totally Enclosed Air Over (TEAO) enclosure for protection in harsh environments
- Ball bearing construction for long service life and reduced maintenance
- 1/2″ x 3″ shaft for secure, versatile mounting
- Reversible rotation for flexible installation configurations
- Permanent Split Capacitor (PSC) design for smooth, energy-efficient starting and running
Motor Specifications
- Horsepower: 1/4 HP
- Voltage: 115 VAC
- Phase: Single Phase
- Speed: 1100 RPM, 2-Speed
- Full Load Amps: 3.4 A
- NEMA Frame: 48Z
- Enclosure Type: Totally Enclosed Air Over (TEAO)
- Bearing Type: Ball Bearing
- Shaft Size: 1/2″ diameter x 3″ length
- Rotation: Reversible
- Motor Type: Permanent Split Capacitor (PSC)
Application & Compatibility
The 48Z NEMA frame and reversible rotation make the Honeywell 009640 a versatile drop-in replacement or new-installation motor suitable for condenser fans, evaporator fans, and air handler blowers. The Totally Enclosed Air Over (TEAO) enclosure shields internal windings from dust, moisture, and debris, making it well-suited for outdoor or exposed indoor installations. The PSC motor design eliminates the need for a start capacitor, simplifying wiring and reducing potential failure points, while ball bearings ensure quiet, long-lasting operation with minimal maintenance requirements.
