Description
The GC Valves S201GH02V5DG4 is a 1/2″ Normally Closed (NC) high-temperature solenoid valve engineered for demanding HVAC, plumbing, and industrial fluid control applications. Featuring durable Viton seals and a rated operating pressure range of 0 to 140 PSI, this valve delivers reliable shutoff performance in elevated-temperature environments where standard elastomers would fail.
Key Features
- Port Size: 1/2″ for versatile system integration
- Operation: Normally Closed (NC) — valve closes when de-energized for fail-safe shutoff
- Seal Material: Viton (FKM) — excellent resistance to high temperatures, steam, oils, and aggressive fluids
- Pressure Range: 0–140 PSI operating pressure
- High-Temperature Design: Built to perform reliably in elevated-heat service conditions
- Compact, direct-acting solenoid construction for quick response
Why Viton Seals?
Viton (FKM) elastomer seals outperform standard BUNA-N or EPDM seals in high-temperature and chemically aggressive environments. They maintain their integrity across a broad temperature spectrum, making this valve an ideal choice for steam, hot water, hydraulic oil, and other demanding media.
Typical Applications
- Hot water and steam control in HVAC hydronic systems
- High-temperature fluid shutoff in commercial and industrial equipment
- Process control lines handling oils, fuels, or aggressive chemicals
- OEM equipment requiring reliable NC solenoid valve performance
Product Specifications
- Brand: GC Valves
- SKU / Model: S201GH02V5DG4
- Port Size: 1/2″
- Valve Action: Normally Closed (NC)
- Seal / Seat Material: Viton (FKM)
- Operating Pressure: 0–140 PSI
- Service: High-Temperature
