Description
The Wayne Combustion 23101-HS is a heavy-duty ignition transformer engineered for dependable spark generation in oil-fired burner systems. Delivering a 10,000-volt secondary output from a standard 120-volt primary supply, this 250VA transformer provides the high-voltage energy needed to reliably ignite fuel at the burner head — even under demanding combustion conditions.
Designed as a direct-fit replacement for compatible Wayne Combustion burner assemblies, the 23101-HS is built to withstand the heat, vibration, and continuous-duty cycles common in residential and light commercial heating applications. Its robust construction ensures consistent ignition performance season after season, minimizing nuisance lockouts and costly service calls.
Key Specifications
- Primary Voltage: 120V
- Secondary Voltage: 10,000V
- VA Rating: 250VA
- SKU / Part Number: 23101-HS
- Compatible with Wayne Combustion oil burner systems
Features & Benefits
- High-voltage secondary output for reliable ignition arc generation
- 250VA rating supports consistent, stable spark delivery
- Standard 120V primary input — compatible with typical residential and commercial power supplies
- Direct OEM replacement for Wayne Combustion burner assemblies
- Durable construction rated for continuous-duty combustion environments
- Helps reduce nuisance lockouts and unplanned service calls
Application
The 23101-HS ignition transformer is ideal for HVAC technicians and service professionals maintaining or replacing components in Wayne Combustion oil burner systems. Whether performing a scheduled tune-up or responding to a no-ignition call, this transformer delivers the high-voltage output required for positive fuel ignition.
