Description
The Dwyer IP-42 is a precision current-to-pressure transducer engineered to convert a standard 4 to 20 mA electronic control signal into a proportional 3 to 15 PSI pneumatic output. This device serves as a critical interface between electronic building automation systems and pneumatic actuators, dampers, and valves — making it an ideal solution for retrofit and hybrid control applications in commercial HVAC systems.
Signal Conversion
The IP-42 accepts a 4 to 20 mA input signal and delivers a linear, proportional 3 to 15 PSI pneumatic output, ensuring accurate and repeatable control response across the full operating range.
Key Features
- 4 to 20 mA current input for compatibility with standard BAS and DDC controllers
- 3 to 15 PSI pneumatic pressure output for driving pneumatic actuators and control devices
- 1/4″ pressure connection for easy integration into pneumatic control lines
- 1/2″ electrical conduit connection for secure, code-compliant wiring
- Compact, durable construction suitable for commercial HVAC environments
- Enables seamless integration of electronic control signals with pneumatic field devices
Typical Applications
- Pneumatic damper actuator control in air handling units
- Pneumatic valve positioner interface in hydronic systems
- Building automation system (BAS) to pneumatic device signal conversion
- Retrofit of pneumatic systems with modern electronic DDC controllers
Connections
- Pressure Connection: 1/4″
- Electrical Connection: 1/2″
